Tika Tika! Getting started doing OCR with Apache Tika andTesseract from the JVM

Published at 2020-04-10 by Nathan Perdijk

Tika Tika! Getting started doing OCR with Apache Tika andTesseract from the JVM (Scala, Java, Kotlin…).

I can do DataScience, mate!

Some things are hard. Some things are not… Turns out that using OCR (Object Character Recognition) using Tesseract from the JVM is… not hard!

The trickiest part, really, is setting up Tesseract on the machine you want to do your OCR on. Once you have managed to do that, you can just use the following Scala examples to use Apache Tika to do OCR in your own JVM project.

First things first. Taking care of your dependencies…

Add these to your pom.xml or other build tool equivalent:

[pom.xml](https://gist.github.com/NRBPerdijk/111fae4189acafb2d75c7c66ba7f2be8#file-pom-xml)

    <dependency>
      <groupId>org.apache.tika</groupId>
      <artifactId>tika-core</artifactId>
      <version>1.24</version>
    </dependency>
    <dependency>
      <groupId>org.apache.tika</groupId>
      <artifactId>tika-parsers</artifactId>
      <version>1.24</version>
    </dependency>

Then, we need to properly configure a Tika Parser

We need one in order to do actually do any parsing. Because this kind of configuration tends to be ugly, I have put it all inside its own object/class to keep it separate from the rest of the code:

[TikaOCRParser.scala](https://gist.github.com/NRBPerdijk/b59332173c9598991f8774d98266e57d#file-TikaOCRParser-scala)

package tika.example

import java.io.InputStream

import org.apache.tika.config.TikaConfig
import org.apache.tika.metadata.Metadata
import org.apache.tika.parser.ocr.TesseractOCRConfig
import org.apache.tika.parser.pdf.PDFParserConfig
import org.apache.tika.parser.{AutoDetectParser, ParseContext, Parser}
import org.apache.tika.sax.BodyContentHandler

object TikaOCRParser {
  private val pdfConfig: PDFParserConfig = {
    val pdfConf = new PDFParserConfig()
    pdfConf.setOcrDPI(100) //scalastyle:ignore magic.number
    pdfConf.setDetectAngles(true)
    pdfConf.setOcrStrategy(PDFParserConfig.OCR_STRATEGY.OCR_ONLY)

    pdfConf
  }

  private val tesseractOCRConfig: TesseractOCRConfig = {
    val tessConf = new TesseractOCRConfig()
    tessConf.setLanguage("eng")
    tessConf.setEnableImageProcessing(1)

    tessConf
  }

  private val parser = new AutoDetectParser(TikaConfig.getDefaultConfig)

  private val parseContext = {
    val parseCont = new ParseContext()
    parseCont.set(classOf[Parser], parser)
    parseCont.set(classOf[PDFParserConfig], pdfConfig)
    parseCont.set(classOf[TesseractOCRConfig], tesseractOCRConfig)
    parseCont
  }

  def parse(inputStream: InputStream, handler: BodyContentHandler, metadata: Metadata): Unit = parser.parse(inputStream, handler, metadata, parseContext)
}

Finally, we have to create…

The code that provides the file to be OCRed.

[TikaOCRApplication.scala](https://gist.github.com/NRBPerdijk/848526c10239f30129e20e8ea9ff6960#file-TikaOCRApplication-scala)

package tika.example

import java.io.ByteArrayOutputStream
import java.nio.charset.Charset

import org.apache.tika.metadata.Metadata
import org.apache.tika.sax.BodyContentHandler

import scala.util.{Failure, Success, Using}

object TikaOCRApplication extends App {
  val input = getClass.getResourceAsStream("/ExampleOCR.jpg")

  val outputStream = new ByteArrayOutputStream()

  val attemptedOCR = Using(input) { inputStream =>
    TikaOCRParser.parse(inputStream, new BodyContentHandler(outputStream), new Metadata())
  }.map { _ =>
    new String(outputStream.toByteArray, Charset.defaultCharset())
  }

  attemptedOCR match {
    case Success(value) => println(s"OCR result was: $value")
    case Failure(exception) => println(s"OCR has failed, exception message was: ${exception.getMessage}")
  }

}

We just turn the file we want to OCR into an InputStream and hand that off to the TikaOCRParser we specified above for parsing. Because using InputStreams and doing parsing are two IO processes that can (definitely) throw Exceptions, I have delegated the handling of the InputStream using Scala’s Using functionality, which will automatically wrap the whole operation into a Try while also making sure that the InputStream is closed when everything is done, even when exceptions are thrown. If the result is a Success, I convert it into a regular String, which can then be printed, or otherwise used at your convenience.

(The example file is a jpeg, but lots of different image formats, as well as PDF, are supported. Some, like JPEG2000, might require extra supporting software to be installed on the machine.)

So, that’s it. Pretty easy, right? Check out the Apache Tika documentation to see what other great functionality is available. Tesseract OCR is a pretty tricky field in and off itself, so be sure to check out all the tweaks you may have to make for your particular dataset. If you want to see the full code for this example, you can check it out on GitHub. Last but not least, kudos to the Apache Software Foundation for their continuing work towards great Open Source solutions.

Edit: I also wrote a short intro using Apache Tika to do Named-Entity Recognition (NER): Tika NERding: Getting started using Named-Entity Recognition with OpenNLP on the JVM.
